MONDRAKER MONDRAKER Raze Carbon RR, deep purple/light blue, 2025 Velikost L
Description and parameters
MONDRAKER MONDRAKER Raze Carbon RR, deep purple/light blue, 2025
MONDRAKER MONDRAKER Raze Carbon RR, deep purple/light blue, 2025
ParametersAdd to Compare
Root
E-shop
Root
B2B
Shop type
SML
Activity
cycling PCI
Category
Hardware
SEO description
Horské kolo
Group
bicycle-HW
Subgroup
mtb-HW BIC
Velikost
L
Eshop size group
size_frame
Size
L
Přehazovačka
Sram X01 Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
Hlavové složení
Acros custom for 1-1/2
Vidlice
Fox 36 29 Float GRIP2 Factory Kashima, 150mm, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: high and low-speed compression, high and low-speed rebound, air preload
Velikosti
S: 380mm / M: 420mm / L: 450mm / XL: 500mm
Rám
Raze 29 Stealth Air full Carbon, Zero Suspension System, 130mm travel, Forward Geometry, Carbon Monoblock upper link, Boost 12x148mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, HHG internal cable routing, Enduro MAX sealed bearings, shock mudguard, ISCG 05, custom frame protectors.
Sedlo
Fizik Antares R7
Materiál rámu
carbon
Dráty
24 straight-pull double butted spokes
Typ vidlice
SUSPENSION FORK
Zadní brzda
Sram G2 RS, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads
Brzdové páčky
Sram G2 RS, SwingLink, tool-free reach adjust
Představec
Onoff Krypton FG 30mm, CNC, 31.8mm barbore
Převodník
32T, CNC-machined alloy, X-SYNC 2
Sedlovka
Fox Transfer Factory Kashima internal, diameter 31.6mm, S size: 363.5x125mm, M size: 418.3x150mm, L/XL size: 475.1x175mm
Středové složení
Sram DUB BSA, sealed bearings, 73mm
Přední brzda
Sram G2 RS, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads
Velikost kol
29
Kliky
Sram X1 Carbon Eagle, Boost, DUB axle, Direct mount chain ring, S/M size: 170mm, L/XL size: 175mm
Počet převodů
1X12
Ráfky
Mavic CrossMax XL S, 29 Boost 30mm internal width, hookless, tubeless ready, 24 spokes
Řídítka
Onoff Krypton Carbon 1.0, rise: 25mm, width: 800mm, 9o backsweep, 5o upsweep, 31.8mm barbore
Řetěz
Sram GX Eagle, 12s, Powerlock
Zadní náboj
Infinity hub, ID360 freewheel technology, Boost 12x148mm, IS 6 bolts
Přední náboj
Infinity hub, Boost 15x110mm, IS 6 bolts
Zadní plášť
Maxxis Aggressor 29x2.3, tubeless ready, dual compound, Exo protection, 60TPI, folding bead
Řadící páčka
Sram Trigger GX Eagle, 12s, X-Actuation 1:1
Přední plášť
Maxxis Dissector 29x2.4 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead
Patka přehazovačky
Sram UDH
Kazeta
Sram XG-1275, 10-52T, 12s
Hmotnost
13,1 kg
Nastavení tlumiče
Light compression, light rebound, air volume spacer 0.6
Zadní tlumič
Fox Float DPS Factory Kashima EVOL LV, 205x57.5mm. Settings: Compression 3 positions lever, low-speed compression, low-speed rebound, air preload. Trunnion top mount, 30x8mm bottom bushings
Sezóna
jaro/léto 25
Pohlaví
unisex
Barva
Mix
Velikost dodavatele
L
MONDRAKER MONDRAKER Raze Carbon RR, deep purple/light blue, 2025
