Rám

Stealth Air full Carbon, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal & removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, integrated dropout speed sensor, exclusive plastic motor covers.

Zadní tlumič

Fox Float X Performance EVOL, 185x55mm. Settings: 2-position compression (Open/Firm), rebound, air preload. Trunnion top mount, 30x8mm bottom bushings

Medium compression, medium rebound, air volume spacer 0.4

Vidlice

Fox 36 29 Float GRIP EVOL Performance, 160mm, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload

Hlavové složení

Acros custom for 1-1/2" head tube, angular contact bearings 40x52x7, Internal cable routing

Představec

Onoff Krypton FG 30mm, CNC, 31.8mm barbore

Řidítka

Onoff Krypton 1.0, rise: 25mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore

Rukojeti

Onoff Desert, 1lock-on, 135mm

Sedlovka

Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 405x95-125mm, M size: 458x120-150mm, L size: 498x140-170mm, XL size: 558x170-200mm

Sedlo

Fizik Terra Aidon Slim X5

Přední brzda

Sram G2 R, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads

Zadní brzda

Sram G2 R, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads

Brzdové páky

Sram G2 R, tool-free reach adjust, lever pivot bushings

Ráfky

Mavic E-CrossRide 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes

Špice

Mavic J-bend double butted, contactless lacing

Přední náboj

Mavic, Boost 15x110mm, IS 6 bolts

Zadní náboj

Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts, HG freehub

Přední plášť

Maxxis Minion DHF 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead

Zadní plášť

Maxxis Minion DHR II 29x2.4 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead

Kliky

E.13 E*Spec Plus,, S size: 165mm M size: 165mm L size: 170mm XL size: 170mm

Převodník

Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD

Řetěz

Sram NX Eagle, 12s, Powerlock

Přehazovačka

Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1

Páka přehazovačky

Sram Trigger NX Eagle, 12s, X-Actuation 1:1

Kazeta

Sram PG-1230, 11-50T, 12s

Patka

Sram UDH

Další

Mondraker custom desing Fidlock smoked transparent 600ml bottle + Fidlock base down version *Optional external battery: TQ 160Wh

Váha

18,9 kg

Displej

TQ HPR display V01

Motor

TQ HPR-50

Baterie

TQ HPR-50 360Wh integrated and removable
